UVA V2X Construction Nvidia AGX Orin Compute Module 64GB

Beijing Plink AI Technology Co., Ltd
Contact Now

UVA V2X Construction Nvidia AGX Orin Compute Module 64GB

  • 1
  • 2
  • 3

Brand Name : NVIDIA

Model Number : AGX orin 64G module

Place of Origin : USA

MOQ : 1PCS

Price : USD1680-USD1700/PCS

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 20pcs 15-30 work days

Delivery Time : 15-30 work days

Packaging Details : 100mm x 87mm 699-pin Molex Mirror Mezz Connector Integrated Thermal Transfer Plate

NAME : UVA V2X Construction Nvidia AGX Orin Compute Module 64GB

Keyword : UVA V2X Construction Nvidia AGX Orin Compute Module 64GB

AI Performance : 275 TOPS

GPU : 2048-core NVIDIA Ampere architecture GPU with 64 Tensor Cores

CPU : 12-core Arm® Cortex®-A78AE v8.2 64-bit CPU 3MB L2 + 6MB L3

Memory : 64GB 256-bit LPDDR5 204.8GB/s

Storage : 64GB eMMC 5.1

Vision Accelerator : 1x PVA v2

Other I/O : 4x USB 2.0 4x UART, 3x SPI, 4x I2S, 8x I2C, 2x CAN, DMIC & DSPK, GPIOs

CPU Max Freq : 1x 8K60 multi-mode DP 1.4a (+MST)/eDP 1.4a/HDMI 2.1

Power : 15W - 60W

Mechanical : 100mm x 87mm 699-pin Molex Mirror Mezz Connector Integrated Thermal Transfer Plate

Contact Now

UVA V2X Construction Nvidia AGX Orin Compute Module 64GB

NVIDIA Jetson AGX Orin Module (64G)

What Is Edge Computing?

At the edge, IoT and mobile devices use embedded processors to collect data. Edge computing takes the power of AI directly to those devices and processes the captured data at its source—instead of in the cloud or data center. This accelerates the AI pipeline to power real-time decision-making and software-defined autonomous machines.

UVA V2X Construction Nvidia AGX Orin Compute Module 64GB

AI is Now Everywhere

As businesses across industries grapple with vast amounts of data, more complex operations, and more dynamic markets, edge AI is playing a growing role in helping them rapidly respond. Through a combination of computing power, AI technology, data analytics, and advanced connectivity, the edge extends compute capabilities from data centers out to the edge of networks, allowing organizations to act quickly on data where it’s captured. Reducing the distance between where data is captured and where it’s processed not only alleviates data transit costs, but also improves latency, bandwidth utilization, and infrastructure costs.

Jetson AGX Orin Module (64GB) Technical Specifications

Brand NVIDIA
Module NVIDIA Jetson AGX Orin 64GB
AI Performance 275 TOPS
GPU 2048-core NVIDIA Ampere architecture GPU with 64 Tensor Cores
GPU Max Frequency 1.3 GHz
CPU 12-core Arm® Cortex®-A78AE v8.2 64-bit CPU
3MB L2 + 6MB L3
CPU Max Frequency 2.2 GHz
DLA Max Frequency 1.6 GHz
DL Accelerator 2x NVDLA v2
Safety Cluster Engine -
Memory 64GB 256-bit LPDDR5
204.8GB/s
Storage 64GB eMMC 5.1
Display 1x 8K60 multi-mode DP 1.4a (+MST)/eDP 1.4a/HDMI 2.1
Camera Up to 6 cameras (16 via virtual channels)
16 lanes MIPI CSI-2
D-PHY 2.1 (up to 40Gbps) | C-PHY 2.0 (up to 164Gbps)
Video Encode 2x 4K60 (H.265)​
4x 4K30 (H.265)​
8x 1080p60 (H.265)​
16x 1080p30 (H.265)​
Video Decode 1x 8K30 (H.265)​
3x 4K60 (H.265)​
7x 4K30 (H.265)​
11x 1080p60 (H.265)​
22x 1080p30 (H.265)​
PCIe Up to 2 x8 + 1 x4 + 2 x1
(PCIe Gen4, Root Port, & Endpoint)
Networking 1x GbE
1x 10GbE
Power 15W - 60W
Other I/O 4x UART, 3x SPI, 4x I2S, 8x I2C, 2x CAN, PWM, DMIC & DSPK, GPIOs
Mechanical 100mm x 87mm
699-pin Molex Mirror Mezz Connector
Integrated Thermal Transfer Plate



A revolution in embedded AI product development.

The rapid evolution of artificial intelligence (AI) and the proliferation of billions of IoT devices are transforming almost every industry. AI at the edge now enables use cases that we could only imagine until recently. Today, the NVIDIA Jetson™ platform brings incredible new capabilities to the edge, accelerating product development and deployment at scale.
